Overview
Key Features
- Sturdy and Durable: This PTO shaft is a well-forged series4 driveline shaft with CE certification. It is built with a solid 20CrMnTi carburized steel universal joint and a Q345 steel tube inside the shield, and selected models also include a slip clutch. The PTO shaft is durable and robust when working with various agricultural machinery.
- 1-3/8" Standard Ends: The tractor end is 1-3/8" x 6 Spline on every model; the implement end is 6 Spline on the clutch models and round on the others (see the options above). Our brush hog PTO shaft matches perfectly with the same size and type of implements and tractors, providing magnificent driving force for your machinery.
- Adjustable Length: Every model is a telescoping PTO shaft - see the options above for the compressed and extended overall length of each size. The tiller PTO shaft is designed with a telescoping steel tube, a universal joint, and yokes. Series 4 rating: 35 Hp, 26 Kw, and 460 Nm torque at 540 rpm, while at 1000 rpm it features 53 Hp, 39 Kw, and 360 Nm torque.
- Easy Assembly ＆ Safer Use: As a high-efficient power transmission tool, our PTO extender shaft can be easily assembled for direct replacement. On models fitted with a slip clutch, it works as an extra security line for the PTO shaft to prevent further damage moving up the line. The security chain and plastic shield eliminate potential dangers in the transmission process.
- Wide Application: The PTO (Power Take-Off) shaft transfers the power from the tractor to the PTO powered attachment. It is widely used on mowers, rotary tillers, tractors, and more. Control the speed and power of your machine effectively. Powerful torque conversion and reliability will leave you wishing you got our PTO shaft sooner.
Specifications
| Brand | VEVOR |
|---|---|
| Product Type | Vehicles & Parts > Vehicle Parts & Accessories > Motor Vehicle Parts > Motor Vehicle Transmission & Drivetrain Parts > Drive Shafts |
| Available Overall Lengths | 41 in / 1050 mm; 55 in / 1400 mm; 59 in / 1500 mm; 61 in / 1550 mm |
| Available Colors | Black / Yellow |
| Series | Series 4 |
| Tractor End | 1-3/8 in x 6 Spline (all models) |
| Implement End | 6 Spline or Round (depends on model) |
| Slip Clutch | Included on selected models |
| Universal Joint | 20CrMnTi Carburized Steel |
| Tube | Q345 Steel with plastic shield |
| Applications | Brush hog, finish mower, rotary cutter, tiller, tractor |
| Available Options | Expand Overall Length: 41"/1050 mm, 55"/1400 mm, 59"/1500 mm, 61"/1550 mm; Color: Black, Yellow |
